Top 10 Screw Air Compressor in Africa
Group 520 1
Click to enlarge
Top 10 Screw Air Compressor in Africa
Group 520 1
Home Oil-Lubricated Screw Air Compressor Low-Pressure Air Compressor Low Pressure Air Compressor
Top 10 Screw Air Compressors in China
Scroll Oil Free Air Compressor
Back to products
Group 536
Micro Oil Injected Booster

Low Pressure Air Compressor

Product Name: Low-Pressure Air Compressor
Gas Type: Air
Power: 22KW – 250KW
Voltage: 220V, 380V, 460V (50Hz/60Hz)
Pressure: 3-5Bar
Outlet Size: G1/2-8″
Lubrication Style: Oil-Lubricated
Drive Method: Fixed Speed / Variable Speed
Warranty: 2-Years
Certification: CE / ISO
Customization: OEM / ODM Available





Category: Low-Pressure Air Compressor Tag: Low Pressure Single-Stage
  • Description
  • Parameters
Description

LOW-PRESSURE AIR COMPRESSOR

Over the years, we’ve been a major player in the manufacturing and distribution of high-quality commercial and industrial screw air compressors and diesel-powered generators. We provide you with standard and unique configurations for an extensive selection of transportable installations.

The Low-Pressure Air Compressor is one among the many types of compressors we have available for you. We also manufacture customized compressors for your specific needs and provide you with the installation and configuration processes.



Get To Know More About Low-Pressure Air Compressors

A Low-Pressure Air Compressor is a type of compressor that belongs to the pressure category and discharges pressure at around 1-10MPa. This piece of equipment provides a steady amount of air, even when the pressure changes. The compressor’s processor comprises two propellers that alternate in the opposite direction. As the gas gets drawn in from the pipe, it goes straight to the shrinking compression side of the compartment at work causing the air to compress.



Product Benefits

Our products come with the following advantages:

·        Low-Pressure Air Compressor has long service life and low cost of maintenance.

·        The product comes with a high protection level design.

·        Comes with low noise and low vibration capabilities. So you don’t have to worry much about environmental pollution.

·        It saves you a lot of energy while providing more efficient service.

·        It can work over an extended number of hours.



General Precaution On Air Compressors

What To Do When a Compressed Air is Slow To Build Pressure

While compressors are designed to perform an extensive collection of tasks, precautionary measures need to be taken. No matter how good the product is, lousy maintenance could tamper with the product’s lifespan. As you provide proper care for your compressor, there are other factors that can cause disruption in your compressor’s operation. One of the effects involves when compressed air is slow to build pressure. We’ve provided you with a few possible reasons why this could happen.

·        Failure in the Compressor Pressure Valve: This is one common factor to look out for. Most times, even when the equipment is on, the pressure cannot produce enough air to be stored in the tank.

·        Failure in the Compressor Intake Valve: Another important thing to watch out for is the intake valve. With a bad intake valve, the air being taken in escapes through the bad valve before it even gets to be compressed.

·        Piston Seal Failure: The compressor has a piston ring that works as the seal that pulls air into the compressor and stops excessive oil from entering the compressor’s cylinders. If one or more piston seal fails to function, the pump finds it hard to maintain the pressure needed for compression.

·        Failure of the Gasket: The gasket separates the pressure valves from the valve plates while in operation. The gasket failure may not stop the machine from working; it will rather prevent pressure from building up.

·        When the Check Valve Tank is Broken: The check valves’ primary task is to stop air flowing from the tank back to the line. When the valve tank is broken, the air flows out without restrictions.



Beyond Low-Pressure Air Compressor

Lerêve Air strives to make you thrive by providing exceptional customer service on our different offerings. Beyond Low-Pressure Air Compressors, we offer other compressed air products such as Dry Oil-Free Air Compressor, Low-Pressure Air Compressor, Mobile Electric Air Compressor, Oil-Flooded Screw Air Compressor, Scroll Oil-Free Air Compressor, Single Phase Rotary Air Compressor, Towable Diesel Air Compressor, Truck-Mounted Diesel Compressor, Two-Stage Screw Air Compressor, and Water Lube Oil-Free Air Compressor. For more details about our extensive list of products, kindly contact us right away.



Want To Learn More About Our Product Prices?

The good news here is that our products are very affordable, notwithstanding how top-quality they are. We ensure that our company offers quality and affordability at the greatest available means. Want to learn more about a product, and get a quote from us? Kindly get in touch with us let’s serve you better.



Parameters
LRVLP- Series Working Pressure Capacity Power Noise Air Outlet Pipe Diameter Net Weight Dimensions (mm)
bar psig (m3/min) cfm kW hp dB kg Length Width

Height

LRVLP-22 (S/T) 3 43 6.31 222 22 30 64±3 DN50 1300 1500 1100 1400
LRVLP-22 (S/T) 4 58 6.29 220 22 30 64±3 DN50 1300 1500 1100 1400
LRVLP-22 (S/T) 5 72 6.18 218 22 30 64±3 DN50 1300 1500 1100 1400
LRVLP-37 (S/T) 3 423 9.28 327 22 30 64±3 DN65 1400 1900 1200 1700
LRVLP-37 (S/T) 4 58 9.15 322 37 50 65±3 DN65 1400 1900 1200 1700
LRVLP-37 (S/T) 5 72 9.0 317 37 50 65±3 DN65 1400 1900 1200 1700
LRVLP-55 (S/T) 3 43 15.07 531 55 75 65±3 DN80 1400 2200 1500 1800
LRVLP-55 (S/T) 4 58 14.2 501 55 75 65±3 DN80 1400 2200 1500 1800
LRVLP-55 (S/T) 5 72 12.8 451 55 75 65±3 DN80 1400 2200 1500 1800
LRVLP-75 (S/T) 3 43 19.27 680 75 100 68±3 DN125 2150 2900 1800 2000
LRVLP-75 (S/T) 4 58 19.15 675 75 100 68±3 DN125 2150 2900 1800 2000
LRVLP-75 (S/T) 5 72 14.60 515 75 100 68±3 DN125 2150 2900 1800 2000
LRVLP-90 (S/T) 3 43 22.25 785 90 120 68±3 DN125 2700 2900 1800 2000
LRVLP-90 (S/T) 4 58 22.03 777 90 120 68±3 DN125 2700 2900 1800 2000
LRVLP-90 (S/T) 5 72 19.21 678 90 120 68±3 DN125 2700 2900 1800 2000
LRVLP-110 (S/T) 3 43 30.81 1087 110 150 74±3 DN125 3800 3000 1900 2000
LRVLP-110 (S/T) 4 58 27.52 971 110 150 74±3 DN125 3800 3000 1900 2000
LRVLP-110 (S/T) 5 72 24.35 859 110 150 74±3 DN125 3800 3000 1900 2000
LRVLP-132 (S/T) 3 43 30.90 1092 132 175 74±3 DN125 4000 3000 2900 2000
LRVLP-132 (S/T) 4 58 29.20 1030 132 175 74±3 DN125 4000 3000 2900 2000
LRVLP-132 (S/T) 5 72 28.60 1009 132 175 74±3 DN125 4000 3000 2900 2000
LRVLP-160 (S/T) 3 43 40.80 1440 160 215 74±3 DN125 5900 3400 2100 2200
LRVLP-160 (S/T) 4 58 38.20 1348 160 215 74±3 DN125 5900 3400 2100 2200
LRVLP-160 (S/T) 5 72 37.5 1323 160 215 74±3 DN125 5900 3400 2100 2200
LRVLP-200 (S/T) 3 43 54.90 1937 200 270 74±3 DN150 7800 4100 2300 2500
LRVLP-200 (S/T) 4 58 50.60 1786 200 270 74±3 DN150 7800 4100 2300 2500
LRVLP-200 (S/T) 5 72 48.30 1704 200 270 74±3 DN150 7800 4100 2300 2500





Let us know your requirements

Feel free to inquire to explore our wide range of screw air compressors.

Request a quote
